18L Square metal carton box making machine

Automatic 18Lretangularmetal carton box making machine, automatic metal can production line. 1.Processes position---- square stretch----imprinting ---flanging bottom---paneling/bottom end seaming--- turn over ---- Flanging cover---paneling/top end seaming 2.Main parameters can height:330-400mmthe max length of the diagonal:324mminstalled power:40 KWpower supply:380V/50Hzaire pressure:0.6MPaoverall dimesnion:8860*2060*2640mmmachine weight:20 Tefficiency:20 cpm 3.Advantages 1.Adopting rotation flanging which can adjust the flanging and necking sizes achieves multifunction2.Achieving 5 layers and 7 layerscan bottom curling and sealing with unique 9 wheels can-sealing technology that can improve the efficiency of production and leaktightness ofcan bottom3.Adopting the structure of inner stretch core makes the can difficult to be deformed that can decrease the material's requirements4.Using servomotor to control the discontinuous running decreases the consumption of electricity5.Decreasing the maintainability of the machine sealing part’s heads without clutch which can prolong the lifetime of the machine sealing part’s heads6.Decreasing the cost of labors and working injury accidents as the full automatic production line only needs 1-2 workersProduct reference:
